CyberLevel
A gyro-stabilized digital level
for Steadicam and camera operators
Features
- High precision level with VR grade gyro fusion
- Ultra light low profile LED bar to mount right next to the monitor to place the level as close to your image as possible
- Touch screen for easy access to all settings via menu
- Automatically transitions from high to low mode
- Zero out / tare function to match the camera position
- Battery level indicator with voltage offset to match the camera
- All settings are saved when powered off
- Highly customizable:
- Selectable voltage for low battery warning
- Voltage offset to match your camera voltage reading
- Brightness and orientation of both LCD and LED bar
- USB or 2 pin Lemo power input 5v to 18v
- Software updatable by user
- More accessories and functions coming later
- Custom case and cable colors
Why CyberLevel?
I first designed the CyberLevel for myself because I wasn’t satisfied with the available options, as a result, I decided to make my own. I wanted a level that has:
- a small footprint on the monitor, no bulk, no weight
- a level indicator as close to the monitor’s picture as possible
- high granularity level indicator with fading LEDs
- easy to use: plug and play, ready to go out of the box
- customizable: the tools should adapt to the operator’s style
Why choose CyberLevel?
- the smallest brain possible with a touchscreen to keep settings easy
- high level precision with fading lights to give you the highest precision level possible
- ultra light and flexible LED strip
- Velcro it to your monitor bezel so the LED bar sits right next to your monitor’s image while keeping the weight to a minimum
- customizable
- 3D printed with PETG infused carbon fiber plastic is super strong and allows for customization
- Customer support provided directly from the maker
Questions? Contact me and I’ll be happy to chat with you.
Specs
Brain
- dimensions: 1.84 x 1.96 x 1.23 in
- weight: 2 oz
- mounting: two 1/4-20 threads, standard 18 mm spacing
- power: 5-18v (USB-C or 2 pin Lemo)
LED strip
- dimensions: 4 x 0.5 x 0.15 in
- weight: 1 oz (that’s mostly the Lemo connector’s weight)
- mounting: Velcro
Mounts (optional)
- Standard 15mm (only use the CyberLevel compatible bridge)
- Studio 15mm (Tiffen M1/M2)
- rod spacing: 100mm
- weight: 2.7 oz
- Universal 15mm monitor yoke (Quattro, XCS…)
- rod spacing: variable
- weight: 4.9 oz
- XCS requires a reducing bushing from 15mm to 1/2 in
Carrying case (optional)
- dimensions: 215x165x90 mm
